Chipset

Chipset: Rockchip
OS: Android 7.1
CPU: Dual-Core 1.8GHz + Quad-Core 1.4GHz
Memory: 4GB DDR, 16GB eMMC

Display

Touchscreen 8-inch, 800*1280

Keys

1 Reset Key

Front Camera

Dual-lens Camera (RGB+IR)

Fill Light

White LED

Contactless Card Reader

ISO14443 Type A/B, ISO18092 compliant

Communications

Ethernet/WiFi 2.4Mhz and 5Ghz/Bluetooth

Temperature   Measurement

Distance : 50   ~ 70cm
Accuracy : ±0.3°C(±0.54°F)
Range: 15-45°C (59-113°F)

Peripheral Ports

1 DC Port, 1 RJ45, 1 micro USB,  1 Wiegand, 1 RS485

Audio

Digital Audio Speaker, Microphone

Power Supply

12V/2A, POE Support with Active Splitter

Bracket (Optional)

Wall Mount Bracket, Turnstile   Mount Bracket

Dimensions (mm)

323 (L)*135 (W)*30 (H)

MDM(Optional)

Mobile Device Management

Certification

CE, FCC, RoHS, Anatel, BIS,Telec
