Chipset

Chipset: Rockchip
OS: Android 7.1
CPU: Dual-Core 1.8GHz(A72) + Quad-Core 1.4GHz(A53)
Memory: 4GB DDR, 16GB eMMC

Display

Touchscreen 8-inch, 800*1280

Keys

1 Reset Key

Front Camera

Dual-lens Camera (RGB+IR)

Fill Light

White LED

Contactless Card Reader

ISO14443 Type A/B, ISO18092 compliant

Communications

Ethernet/WiFi 2.4Mhz and 5Ghz/Bluetooth

Temperature   Measurement

Capability   : 1 person at a time
Resolution :   80*64
Distance    : 1 ~ 2m
Accuracy : ±0.3°C(±0.54°F)
Range: 15-45°C (59-113°F)

Peripheral Ports

1 DC Port, 1 RJ45, 1 micro USB,  1 Wiegand, 1 RS485

Audio

Digital Audio Speaker, Microphone

Power Supply

12V/2A, POE Support with Active Splitter

Bracket (Optional)

Wall Mount Bracket, Turnstile   Mount Bracket

Dimensions (mm)

317 (L)*135 (W)*31 (H)

MDM(Optional)

Mobile Device Management

Certification

CE, FCC, RoHS
